product application: suitable for industrial and commercial buildings, distribution systems and other fields

rated operating voltage (ue): 12kv

rated current (in): 800/1250a

rated frequency: 50/60hz

rated short-duration power frequency withstand voltage: 28kv in compliance with iec 62271-200

rated lightning impulse withstand voltage: 75kv

rated short-time withstand current: 25ka 3s

rated peak withstand current: 63/65ka (50/60hz)

rated short-circuit breaking current: 25ka

rated short-circuit making current: 63/65ka (50/60hz)

internal arcing classification:

accesibility (front, rear, lateral): type a

test current: 25ka

arc duration: 1 second

partition class: pm (metallic partition)

loss of service continuity category: lsc2b (metal-clad)

design specification: designed and tested in compliance with iec 62271-200 and vde 0671-200
