product application: household and final circuits

number of poles: 1pn, 2p, 3pn, 4p

rated current (in): 63a

rated operate voltage (ue):ac230v/400v

rated insulation voltage (ui): ac500v

rated impluse withstand voltage (uimp): 4kv

tripping sensitivity (iδn): 30ma, 100ma, 300ma

breaking capacity:

icn=6ka, ac400v

ics=100%icu

conform to the standard: iec 61009-1, bsen 61009, gb/t 10917.1, gb/t 16917.22

certificate: ccc ce cb
